FOR BUSINESSESFood processing
Packaging-line tooling outside food contact
Jigs and holders are selected for mounting, loads and cleaning conditions.
Reference part · Format setup template
120 × 70 × 15 mm · PA12 · Reference geometry: positioning plate for line conversion.
- mass per part
- 45.5 g
- working hours for a quotation
- 24 h
We confirm pricing, currency, lead time and delivery terms individually for international orders.
Parts we make for this application
8 examples
- Conversion and format setup templates
- Sensor and photoelectric sensor grips
- Guards, covers, and plugs
- Positioning elements outside the product zone
Show 4 more examples
- Guides for bulk packaging
- Cable and installation supports
- Control templates for inspections
- Spare parts for machines outside the product washing zone
0.2%
PA12 specimen mass gain after 24 h: 3.5% NaCl, isopropanol and 3% H₂O₂
What powder sintering offers
The result covers an immersed 1 × 1 × 1 cm cube, not a finished holder. It does not confirm hygiene, leak-tightness or cleaning-cycle resistance. State agent, concentration, temperature and contact duration; food-contact parts remain outside scope.
PA12 chemical resistanceWhat this process cannot do here
No fine print
- We do not have food-contact approved powder: neither PA12 White, nor Food Blue, nor the metal detector detectable version.
- Compliance with EC 1935/2004 covers both the raw material and the entire production process. We do not declare it.
- We do not issue compliance declarations or documentation for HACCP audits.
- PA12 specimen HDT of 87 °C at 1.8 MPa does not establish continuous service temperature. Loaded parts in tunnel washers remain outside scope.
- We do not have ISO 9001 and do not claim to have it.
How your project moves forward
- Where will it operate?Tell us whether the part is in a food-contact area or outside it. This is our first check.
- Model and cleaning conditionsModel or dimensioned photos. State medium, concentration, temperature and contact duration.
- Workstation trialFits, inspection after cleaning and adjustment scope are agreed before making a trial part.
- Set confirmationQuantities and build layout are checked from models. The 5–14 business days window is confirmed in the quote.
What the quotation covers
A complete set of templates is quoted as one order. Preparation of a new file: PLN 150.00 net. This fee is spread over the quantity; SLS quantity discounts start at 100 parts.
We confirm pricing, currency, lead time and delivery terms individually for international orders.
What to prepare for a quote
Position and geometry
Workstation photos, model or drawing, units and function. Mark datums, mounting and fits. We do not accept food-contact parts.
Cleaning and loads
Agent name, concentration, temperature, duration and cleaning frequency. State forces, motion and oil/water exposure; specimen data do not establish finished-part hygiene.
Trial and quantities
Quantities, date and inspection criteria after mounting and cleaning. Describe required documentation. Model, trial and adjustment scope are confirmed before work.
Send what you have. We will clarify the remaining details when reviewing your enquiry.
How to order
I have a 3D model
Upload your model and choose the parameters. SLS and FDM prices are indicative; an engineer quotes SLA.
Discuss the line fixtureI need a model
Attach photos with a ruler or a drawing. Describe the application; model preparation is quoted separately.
Send photos and a descriptionFrequently asked questions
Can a part touch the product?
Not from our material. If any permitted powder enters the offer, we will note it here along with the card number. Until then, the answer is 'no'.
Will the part withstand chemical cleaning?
The TDS describes cube mass gain after 24 h immersion. It is not a repeated-cleaning, pressure or finished-holder disinfection trial. State agent, concentration, temperature, duration and cleaning frequency; assessment and trial scope are agreed.
Can you reproduce a part for a twenty-year-old machine?
Send a sample or ruler photos of the mount, machine identification and mating parts. A scan also records wear; target fits are established from measurements or documentation. Model, print and trial-fit scope are quoted separately.
How quickly during downtime?
Standard mode is 5–10 business days from order confirmation with a ready model. Priority availability and terms are reviewed individually. Measurement and modelling have a separate schedule.
Coloring by zone colors?
Possible from 20 parts with an individual quote and shade agreed on a sample. Dyeing does not establish cleaning resistance or replace marking required by procedure.
What do we check before ordering the set?
Position outside food contact, mounting, clearances and loads. Identify cleaning and assessment criteria after a workstation trial. Inspection and adjustment scope are confirmed before work; we do not provide food-contact approval documentation.
