FOR BUSINESSESDesigners
SLS prototypes for fit and function trials
Check fit, mechanism movement and part behaviour before ordering a series.
Reference part · Blower impeller
⌀96 × 28 mm · PA12 · Demo calculator file: 48 blades of 1 mm each, sintered into one piece.
- mass per part
- 38.6 g
- working hours for a quotation
- 24 h
We confirm pricing, currency, lead time and delivery terms individually for international orders.
The reference part model is available to download.
Material, quantity, finishing and file preparation affect the price. Compare results with the same settings; a technologist confirms the quotation.
Parts we make for this application
7 examples
- Functional prototypes before deciding on a production run
- Samples for load and fatigue testing
- Form-and-fit models to verify assembly
- Geometric variants printed side-by-side
Show 3 more examples
- Print-in-place assemblies for clearance and motion trials
- Pilot series with an agreed model revision
- Ergonomic mockups for grip evaluation
50 MPa
PA12 specimen ultimate tensile strength (ASTM D638 Type 1)
What powder sintering offers
50 MPa is a specimen result, not allowable stress or prototype service life. Geometry, orientation and operating conditions affect the part. Trial scope and assessment criteria are agreed before producing variants.
PA12 Material Data SheetWhat this process cannot do here
No fine print
- If the production run is injection molded, a sintered prototype checks the housing and grip but does not replace the tooling trial. Shrinkage behaves differently in that case.
- We do not declare one tolerance for an entire model. Identify critical dimensions, datums and clearances; inspection and trial-fit scope are agreed before printing.
- We do not conduct tests: fire, aging, or certification. We provide numbers from the datasheet and state what is missing from it.
- We do not accept prototypes of safety-critical parts, nor as a single test-only unit.
How your project moves forward
- Model and revisionSTL, 3MF or STEP. State units, revision and mating surfaces.
- Variants and quantitiesIdentify files and quantity per variant. Build layout is assessed for the set.
- Your trialTrial purpose, conditions and criteria are confirmed in the quote. Check the part in its installation.
- Series revisionConfirm model and quantities after the trial. Changes and adjustment scope are quoted separately.
What the quotation covers
The indicative price depends on model volume, material and finishing. Preparation of a new file: PLN 150.00 net. The calculator spreads the minimum and preparation over the series; SLS discounts start at 100 parts.
We confirm pricing, currency, lead time and delivery terms individually for international orders.
What to prepare for a quote
Trial purpose and criteria
State what you are testing: fit, motion, load or appearance. Include measurable assessment criteria, forces, temperature, duration or cycle count.
Model and revisions
Model or drawing, units and revision per variant. Mark datums, tolerances, mating surfaces and planned orientation if already agreed.
Variants and acceptance
Quantity per variant, date and intended series process. State the fit-check and inspection method; production, measurements and adjustment scope are agreed separately.
Send what you have. We will clarify the remaining details when reviewing your enquiry.
How to order
I have a 3D model
Upload your model and choose the parameters. SLS and FDM prices are indicative; an engineer quotes SLA.
Quote my prototypeI need a model
Attach photos with a ruler or a drawing. Describe the application; model preparation is quoted separately.
Describe the prototype and testFrequently asked questions
What makes this win over an FDM prototype?
SLS sinters powder instead of depositing filament tracks. It still builds layers: PA12 elongation at break is 11% in X/Y and 6% in Z. We choose orientation for the load; the process does not guarantee freedom from cracking.
How do we compare a trial part with the series?
Agree revision, material, orientation, finishing and dimensions to inspect. The same machine does not guarantee identical parts. One trial result does not confirm the whole series; acceptance scope is agreed before production.
How many variants fit in one load?
The calculator estimates copies of one model, not a mixed build of variants. Files, orientations and quantities are checked in PreForm with 5 mm spacing. Build count and preparation of each revision are confirmed in the quote.
What happens to our files?
Files are kept privately and remain available for 90 days from the enquiry. After that, they are scheduled for deletion during housekeeping. We agree an NDA before you first send files.
When is it better to use resin?
Consider SLA for visible surfaces and fine detail. Selection also depends on forces, temperature, duration and the series process. Assess the specific resin data and a part trial separately; the process name alone is insufficient.
How do we define the outcome of a prototype trial?
State function, conditions, forces, duration or cycles, and fit and function criteria. Identify variants and inspection dimensions. Production, measurement and adjustment scope are agreed in the quote; we do not perform certification testing.
Send your part for a quote
We confirm pricing, currency, lead time and delivery terms individually for international orders.
Quote my prototype Describe the prototype and testQuick contact
Would you like to discuss it?
Leave your phone number or email. We can discuss the part, quantity and deadline before you send a model.
