FOR BUSINESSESBoatbuilding
Custom yacht hardware
Cable fittings, covers and brackets made to fit the boat. We select the material for the installation location and operating conditions.
Reference part · Deck cable conduit
70 × 70 × 25 mm · PA12 · Reference geometry: collar with sealed passage.
- mass per part
- 22.2 g
- working hours for a quotation
- 24 h
We confirm pricing, currency, lead time and delivery terms individually for international orders.
Parts we make for this application
8 examples
- Cable fittings and deck cable glands
- Guide strips and slides
- Equipment brackets and bundle mounts
- Covers and plugs for mounting holes
Show 4 more examples
- Shims, spacers, and mounting washers
- Sensor housings and boxes
- Cover fasteners and upholstery components
- Jigs and assembly templates for boatbuilders
0.2%
PA12 sample weight gain after 24 h in 3.5% NaCl salt water (TDS)
What powder sintering offers
The manufacturer immersed a printed 1 × 1 × 1 cm cube in the solution for 24 h. The result concerns sample weight gain, not the service life of hardware at sea. Permanent immersion, sun exposure and loads require a separate application assessment.
PA12 chemical resistanceWhat this process cannot do here
No fine print
- We do not produce anything from rigging or load-bearing hardware: blocks under load, mast fittings, steering system components.
- We do not manufacture parts responsible for water safety and do not issue classification approvals.
- We do not declare UV resistance. We have not tested it, and the deck is the worst place to guess. A part permanently exposed to the sun requires testing on your end.
- PA12 HDT is 87 °C at a test stress of 1.8 MPa. This is a sample-deflection test result, not an allowable continuous operating temperature. For a part near an engine, provide temperature, duration and loads.
- We do not manufacture pressure vessels or fuel system components under pressure.
How your project moves forward
- File or the partSend a model, drawing or existing fitting to reproduce.
- Material for the environmentTell us whether the part is submerged, splashed or used only inside the cabin.
- Series estimateSend the model and quantity. We will check the batch cost from the geometry and chosen lead-time mode.
- Printing and dispatchLead time: 5–14 business days. The shared-build option gives a 8% discount.
What the quotation covers
Small fittings can be printed together in the chamber. The indicative unit price includes the minimum and preparation spread over the ordered quantity. SLS quantity discounts start at 100 parts.
We confirm pricing, currency, lead time and delivery terms individually for international orders.
What to prepare for a quote
Mounting
Photos of the part and its installation. Include hole spacing and mating-component dimensions.
Environment
Fresh or salt water, sunlight, temperature and exposure time. We do not declare UV resistance.
Function and quantity
What does the part hold, and what loads act on it? Include quantity and timing. We decline safety-critical hardware.
Send what you have. We will clarify the remaining details when reviewing your enquiry.
How to order
I have a 3D model
Upload your model and choose the parameters. SLS and FDM prices are indicative; an engineer quotes SLA.
Quote the hardwareI need a model
Attach photos with a ruler or a drawing. Describe the application; model preparation is quoted separately.
Send photos and a descriptionFrequently asked questions
Will it survive a season on board?
The datasheet gives water and salt-water test results, not a guarantee for a full season on deck. We have not tested UV resistance ourselves. For continuous sun exposure, test one trial part in its actual conditions before ordering a series.
PA12 or PA11?
The TDS lists ASTM D570 water absorption of 0.66% for PA12 and 0.07% for PA11. These results do not determine performance during permanent immersion. Tell us the environment, temperature, loads and required fits; we will select the material and trial scope.
Do you make custom parts for older boats?
Yes, this is a typical order: a part from a manufacturer who no longer produces it. We recreate the geometry from measurements or a scan; the original returns along with the new part.
Will I receive a certificate or approval?
No. We provide data from the manufacturer's powder TDS cards, and that is the complete documentation we issue. Items requiring classification are not for us.
Send your part for a quote
We confirm pricing, currency, lead time and delivery terms individually for international orders.
Quote the hardware Send photos and a descriptionQuick contact
Would you like to discuss it?
Leave your phone number or email. We can discuss the part, quantity and deadline before you send a model.
