REPLACEMENT PARTSGears
Replacement gears from your sample or model
Send the worn gear or a model. We assess the tooth profile, hub and required fit before quoting.
Reference part · Gear z26 m3
⌀84 × 15 mm · PA12 · Reference geometry: straight teeth, module 3, face width 15 mm.
- mass per part
- 62.6 g
- working hours for a quotation
- 24 h
We confirm pricing, currency, lead time and delivery terms individually for international orders.
Parts we make for this application
8 examples
- Cylindrical gears with straight teeth
- Chain sprockets for roller chain
- HTD and T timing pulleys
- Sectors and racks
Show 4 more examples
- Pulleys for home appliance and automation drives
- Lead screws for steel screwjacks
- Hubs with protrusion, wedge, and multi-protrusion designs
- Matching pulley pairs manufactured together
11% · 6%
PA12 elongation at break in X/Y and Z axes, ASTM D638
Why SLS for this part
These elongation values show that print orientation matters. We ask about the load direction before reproducing the tooth profile; the datasheet describes test specimens, not the life of your gear.
PA12 Material Data SheetWhat this process cannot do here
No fine print
- We will not replace a steel pulley transmitting high torque.
- PA12 HDT is 87 °C at 1.8 MPa in the test. We decline loaded gears above 87 °C. Below that temperature, we also assess load and operating duration.
- We do not produce wheels for steering systems, braking systems, or lifting people.
- We do not reproduce manufacturer markings and logos.
- For a module below approx. 1 mm, the tooth profile goes to SLA or machining.
How your project moves forward
- Photos or the gearSend tooth count, diameter, face width and hub bore, or send the gear by courier.
- Reconstruct the profileWe recreate a parametric model from the calculated gear module.
- Trial partBacklash is chosen for dry-running or lubricated operation.
- Shared buildShared B2B build: 10–14 business days, 8% discount. We confirm timing and price for the ready model.
What the quotation covers
Gear printing and profile reconstruction are quoted separately. SLS B2B minimum: PLN 299.00 net; preparation of a new file: PLN 150.00 net. A single gear for a private customer is quoted from photos.
We confirm pricing, currency, lead time and delivery terms individually for international orders.
3D Scanning · EinScan Rigil
We measure worn parts instead of guessing
Photographs with a ruler help assess scope. Simple dimensions can be measured manually; we consider scanning for free-form surfaces. Wear is recorded as the part's condition; reconstruction dimensions are agreed separately.
- Laser HD specification, 100 mm part
- 0.046 mm
- Scan and Mesh, from
- PLN 250.00
Manufacturer's Laser HD data; not a measurement of your part or a printed-part tolerance.
What remains with you
- MeshRecords accessible surfaces in their current condition, including wear. A mesh can be edited, but has no operation history or dimensions from a parametric CAD model.
- Solid modelReconstructs geometry using scans, measurements and available documentation. We agree critical dimensions and assumptions; a parametric model is created where possible.
- Deviation reportComparison with supplied CAD: a deviation map on scanned surfaces and agreed sections. We agree inspection scope and alignment datums before work; unseen areas remain outside measurement.
What to prepare for a quote
Teeth and hub
Photos of the whole gear, teeth and bore with a ruler. Module and tooth count help if known.
Gearbox
The mating gear, shaft mounting and wear location. Describe torque or the drive function.
Operating conditions
Speed, temperature at the gear, operating duration and lubrication. Include quantity and timing.
Send what you have. We will clarify the remaining details when reviewing your enquiry.
How to order
I need a model
Attach photos with a ruler or a drawing. Describe the application; model preparation is quoted separately.
Send photos and a descriptionI have a 3D model
Upload your model and choose the parameters. SLS and FDM prices are indicative; an engineer quotes SLA.
Quote a gear from a modelFrequently asked questions
I have two pieces left. Is that enough?
Usually yes, as we read the tooth count from the rim fragment. Please send both pieces, not just one.
Does it last as long as the original?
Replacement durability requires assessment of geometry and operating conditions. State torque, speed, temperature and lubrication. We agree how the trial gear will be checked before producing a batch.
What tooth clearance do you specify?
This depends on dry or lubricated operation and the mating gear's material. Therefore, please provide a photo of the entire assembly.
Is this legal?
Reproduction depends on rights in the part. The repair clause concerns certain design rights; it is not a general licence to copy and does not override patents. We do not reproduce logos. We clarify unclear rights before work starts.
How long does it take?
We agree measurement and profile reconstruction timing after assessing the gear. Printing from a ready model takes 10–14 business days in shared-build mode or 5–10 business days in standard mode, from order confirmation. Build availability, fit checks and any adjustments are agreed in the quotation.
Send your part for a quote
Attach photos with a ruler or a drawing. Describe the application; model preparation is quoted separately.
Send photos and a description Quote a gear from a modelQuick contact
Need help describing the part?
Leave your phone number or email. Tell us which part broke and we will help identify the information needed for a quote.
